MYLAR® A polyester film is obtained from polyethylene terephthalate, the polymer formed by the condensation reaction between ethylene glycol and terephthalic acid.
Maximum operating temperature: 130°C (up to 150°C) - Class B
Minimum operating temperature: -70°C
Characteristics: insulating paper suitable for insulating transformers, in motor slots for covering cables and conductors, capacitors, membrane switches and in all those electrical applications that require:
excellent electrical insulation - excellent mechanical resistance - good thermal resistance.
Availability:
Original rolls: 1000 ST (Mylar® 1000 mm - 1000 mm useful), 500 SM rolls of 1000 ST cut in half.
Cut rolls: from 6.9 mm high, internal diameter (ID) 76 mm, external diameter (OD) on request.
Color: transparent 0.023 – translucent all other thicknesses
We process both the insulating papers normally in stock and other insulating papers upon customer request.
Any type of insulating paper can be supplied as follows:
- Original rolls, whole or unwound
- Rolls cut to the customer's requested width
- Bordered rolls
- Slit rolls
- Customized processing (e.g., shaped, die-cut, lunettes, tiles, etc.)
Approved - Approved UL (Underwriters Laboratoires Inc.) DU PONT file E93687(R)
MYLAR® is a registered trademark / trade mark Du Pont de Nemours
