VOLTAFLEX® F 6642 (DMD Saturated) – Class F 155°C

VOLTAFLEX® F 6642 flexible insulating composites are made by hot-melting a polyester film intercalated with two layers of polyester non-woven fabric (TNT) and impregnated with a high-thermal resin, ensuring the polyester's resistance to thermal aging. The polyester film, by varying its thickness, allows for a wide
range of composites to be obtained.

Maximum Operating Temperature: Class F – 155 (IEC 60626)
Class F - 155°C (UL 1446)
Minimum Operating Temperature: Resin -60°C / Polyester -60°C

Insulating paper suitable for insulating transformers, in slots, in motors and in all electrical equipment requiring:
excellent electrical insulation – excellent mechanical resistance – excellent thermal resistance.

Availability: Rolls 1000 mm high, rolls cut starting from 7 mm high, internal diameter 76 mm

Color: White or Pink

We process
both the insulating papers normally in stock and other insulating papers upon customer request. Any type of insulating paper can be supplied as follows:
- Original rolls, whole or unwound
- Rolls cut to the customer's requested width
- Bordered rolls
- Slit rolls
- Customized processing (e.g., shaped, die-cut, etc.)

VOLTAFLEX® is a registered trademark of ISOVOLTA Group
