SILICONE GLASS TUBE SCS 1.5kV – 3kV – 4kV – Class C 220°C

• Temperature class: C
• Continuous operating temperature: -60°C to +250°C
Peaks at +290°C (few hours)
• Dielectric strength: 1.5 kV - 3.0 kV - 4.0 kV
• Flammability: self-extinguishing
• Good mechanical resistance • Good
UV resistance
• Good resistance to transformer oils
• Good compatibility with impregnation paints of the same thermal class
• Good behaviour with welding
• Good behaviour with liquid fuels: does not decompose
• Halogen-free
• Waterproof
• Flexible
• Fireproof

OPTIONS:
Can be woven with fibreglass or polyester yarn and painted with a paint from our range

COLOURS AND PACKAGING
• Product diameters: from 0.5 to 60 mm
• Standard colours: Brick red, black
• Other colours: green, blue, red, orange, yellow, white, grey

Standard packaging:
• Diameters 0.5 mm: 400 m
• Diameters from 0.8 to 1.5 mm: 300 m
• Diameters from 2 to 6 mm: 200 m
• Diameters from 7 to 12 mm: 100 m
• Diameters from 13 to 20 mm: 50 m
• Diameters from 22 to 25 mm: 30 m
• Diameters from 26 to 50 mm: 30 m
• Diameters from 55 to 60 m: 15 m

UL UZIQ2 approved
